TerrySRIV6
Member
Registered: 12th May 08
User status: Offline
|
Anyone got any pictures of Corsas with Tigra front ends??? need to convince the GF, did a search but all i got was broken links and missing images
|
TerrySRIV6
Member
Registered: 12th May 08
User status: Offline
|
pweeeeeeease
|
Fonz
Premium Member
Registered: 12th May 06
Location: Newbury, Berks
User status: Offline
|
the Tigra is a Corsa Hybrid!
|
deex
Member
Registered: 9th Nov 07
Location: portsmouth
User status: Offline
|
|
deex
Member
Registered: 9th Nov 07
Location: portsmouth
User status: Offline
|
|
deex
Member
Registered: 9th Nov 07
Location: portsmouth
User status: Offline
|
![](http://img.photobucket.com/albums/v687/Novadose16/S6300166.jpg)
![](http://img.photobucket.com/albums/v687/Novadose16/S6300165.jpg)
|
JM_16v
Member
Registered: 17th Oct 05
Location: Essex Drives: GLC63S
User status: Offline
|
anyone got a pic of a tigra with a corsa front end?
|
mwg
Member
Registered: 19th Feb 04
Location: South Lakes
User status: Offline
|
looks crap
|
deano87
Member
Registered: 21st Oct 06
Location: Bedfordshire Drives: Ford Fiesta
User status: Offline
|
quote: Originally posted by JM_16v
anyone got a pic of a tigra with a corsa front end?
|
XSIHardy
Member
Registered: 5th Feb 08
User status: Offline
|
i dont mind the top one
but the alloys make it look a lot worse
|
TerrySRIV6
Member
Registered: 12th May 08
User status: Offline
|
Cheers
|
swill_omnibus
Member
Registered: 12th Dec 07
Location: : S. wales Drives: Dodge Caliber
User status: Offline
|
How hard is that conversion?? Didn know it was possible!!
|
TerrySRIV6
Member
Registered: 12th May 08
User status: Offline
|
quote: Originally posted by swill_omnibus
How hard is that conversion?? Didn know it was possible!!
I saw it before, and i knew about it, now seeing as my £50 project corsa needs basically a whole front end i thought WHY NOT???
|
chunk89
Member
Registered: 16th May 07
Location: Huddersfield
User status: Offline
|
looks kind of like a starlet if u sqwint a little
|
Ste L
Member
Registered: 3rd Jul 06
Location: Manchester Drives: 106 16v Rallye
User status: Offline
|
the green one's a mates..
also got another mate with a pearl white corsa with a tigra front end too
|
deano87
Member
Registered: 21st Oct 06
Location: Bedfordshire Drives: Ford Fiesta
User status: Offline
|
Apparently it's a complete ball ache conversion and not as easy as some people think
|
Ste L
Member
Registered: 3rd Jul 06
Location: Manchester Drives: 106 16v Rallye
User status: Offline
|
your not wrong deano...
tigra bonnet, slampanel, headlights and 2 wings and a bumper needed, and alot of welding, and filling....
I thought the wings would bolt straight on but i was very wrong.
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00897.jpg)
As you can see i had to cut the corsa wing and weld it to the front of the tigra wing, this was the only way to do it as the door gap was a mile off i could get my hand threw it! So yeah had to cut and weld them together:
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00895.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00899.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00902.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00903.jpg)
The bonnet was then trial fitted with the wings:
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00898.jpg)
To get the wings to sit right against the bonnet the inner wings had to be "modyfied", because the tigra wing is more curved at the top, I had to cut a slit right down it and then squash it round and then re-weld it back together, this was then all seam sealed etc...
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00940.jpg)
The old front panel was then cut off and the new one trial fitted then welded into place.
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00892.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00904.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00905.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00941.jpg)
The headlights were then fitted to see how they lined up:
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00906.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00907.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00908.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00911.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00912.jpg)
All was then welded up and then the engine bay was prepped and primed:
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00942.jpg)
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00943.jpg)
The wings were then bogged up and sealed etc.. and then primed too:
![](http://i57.photobucket.com/albums/g207/vauxtillidie/Corsa%20SRi%20Pickup/DSC00978.jpg)
[Edited on 23-05-2008 by Ste L]
|
deano87
Member
Registered: 21st Oct 06
Location: Bedfordshire Drives: Ford Fiesta
User status: Offline
|
![](/board/images/smile/eek.gif)
So how safe would that be in an impact?
|
Ste L
Member
Registered: 3rd Jul 06
Location: Manchester Drives: 106 16v Rallye
User status: Offline
|
as safe as a corsa really
|
deano87
Member
Registered: 21st Oct 06
Location: Bedfordshire Drives: Ford Fiesta
User status: Offline
|
Fair enough.
|
curtis-lee
Member
Registered: 11th Dec 11
User status: Offline
|
I want my car doing like this :O .. How much would you charge to do it ste??
|
big eck
Member
Registered: 20th Apr 03
Location: Tullibody. Drives - Audi B8 S4 & Fiesta Zetec-S
User status: Offline
|
Why not just buy a tigra
|
Jake
Member
Registered: 24th Jan 05
User status: Offline
|
quote: Originally posted by big eck
Why not just buy a tigra
agreed. putting a corsa rear end on a tigra is just as easy
|
Jambo
Member
Registered: 8th Sep 01
Location: Maidenhead, Drives: VXR Arctic
User status: Offline
|
quote: Originally posted by big eck
Why not just buy a tigra
|
N3CRO
Member
Registered: 12th Apr 07
Location: Sandy, Bedfordshire
User status: Offline
|
Looks awful tbh.
|
